PS> I may have the wiring diagram for the lenze board
All the explanation was awesome :)
Sorry for the delay with this. Can I ask have you managed to get the Boxford to run using Mach3 without upgrading all the stepper drives? I did look at this but it looks a bit messy trying to tap into the original stepper drives. I have managed to get my machine running by just bypassing the main stepper drive board and installing my own stepper drives in the cabinet. I have disconnected the power from the original board. The Bradford board I believe is something to do with the tool change system (Z axis), although I think there is a sensor on the spindle for possibly height and angle to aid tool changing which I belive could be performed using a macro in mach3 (apparently).
On running my machine the stepper drives keep missing steps (so a circle becomes a spiral), I think this is mainly due to them being really cheap ones off fleebay. I am thinking of upgrading the stepper drives and totaly ripping out the original boards and starting again.
To those of you who have been trying to contact me to get the wiring diagrams. I do still have them but cannot reply to your private messages as your accounts are set to not receive replies!
I do not frequent these forums regularly so you will have to contact me offline. I can be reached on simon (at) byte (hyphen) sized (dot) com
Hi Simon, if you can send me the wiring Diagram of the 190, than this will help me a lot, with the modifications of my new 165HMC. It seems, it has the same controller Board, but for the 4th axe it use the same external board double (but why, it seems, the board can control 2 stepperdrivers) , like in the 190. Today I tried to make a single step with a separate momentswitch, but unfortunately without success. The driver for the tool turret seems the same as from the 125 and 160TCL. Only a DC supply with not many regulations, that stops after each 45°, with a simple NC switch. I have 4 relays and a bigger one for the switch on of the control unit. One is for the doorswitch, the second one switch the spindle motor on or off, i can regulate the controller with the switch on the front control panel. But I don't know, what the 2 other do.
Ok in the meantime I know what are the other relays.
the middle switches the spindle Motor on and the last (near the On relay) changes the direction. The complete machine runs, without any issues in Tipmode.
of the spindle.
Last edited by uli12us; 16-11-2015 at 06:06 PM.
4 Weeks Ago #16
I am trying to convert a Boxford VMC 190 using aCNC-USB box from Eding. I found that the output voltages to the motor drives from the boxford processor (xd, xc, zd, zc, cl5 and cl6) and the Eding CNC-USB box to be similar. Since the eding software has some setup functions it is also possible to tweak these voltage vales to match the Boxford processors voltage. While I still haven't checked the spindle voltage levels, My idea is to simply replace the boxford processors pins with the Eding CNC-USB box pins since the signals they both output seem to match. However I am new to this and any advice would be great. By the way do any of you guys have the hardware wiring schematics of the Boxford VMC 190?
