Hmmm feed overide, ok ill have a look and if i can find it is will let you know. lol
Printable View
Hmmm feed overide, ok ill have a look and if i can find it is will let you know. lol
it's on the program run screen, and it's the third box on the bottom "feed rate"
ok Feed rate is 1000. units 0.0 fro 100%
are you typing in g0x--- for the movement in the midi line
Just thought i'd chase this up mate, where are you.????
Hi i2i, sorry ive not been around for some time ive been moving into a larger workshop and doing all the overtime i can to pay for it, the machine ran really well and was surprisingly accurate for its age, I will stick some video up of it working on a test piece, my filming skills are not as good as they could be, but it will show the machine working thanks to all the help ive had on this forum.
Rick
Great to see you've got it all up and running, how are all those lights:tongue:.
Good news on the larger workshop.
Well the lights are not on it yet, The ridicule has given me second thoughts :lol: well here is the link to the video of the first runs of the machine, and yes i am messing around at the back with the speed of the spindle.
http://www.youtube.com/watch?v=BUdhhzArO0g
there will be three videos in all. the test job is an oil cooler end plate for a suzuki bandit.
seems to be working well, it'll not be the same without the lights.:cool:
I had a feeling that you hadn't got the lights working as there was no news of a Kent substation failing.
I actually found an old 260 vmc front panel, in one of my bits boxes.
Switches with lights, are you drooling yet:eek:
:surprised:--:eek:--:cry: erm.....:nope:or whats it like then? LOL
i'll take a pic tomorrow and post it up
I've just looked back through this thread, and it's the same as your original front panel.
I'd like to know how you're holding the aluminium plate down in that video? Some sort of adhesive?
Ahh yes well spotted:naughty:, the aluminium plate has a 10mm edge profile but steps out to 18mm thick 50-100mm in from the edge, the mdf has a machined socket to accept the 8mm step and yes you are correct there is double sided sticky tape to hold it firmly in place together with a tight fit, this allows me to repeat the process without having to set things up each time.( i have several pieces of stock the same size and profile) I just slot the new material in the socket push down firmly and hit the cycle start button in mach3
Ok, so to begin with ive jotted an idea down in paint, there are no dimentions at the moment as i will have to base any measurements on the toolholder and the type of collets, im hoping you will all help me design this little addition with input such as bearing type tool holder type and collet type (not too expensive) the drawing is just a basic concept..
So chirp in if you have any input :idea:
Attachment 4308
Rick
Ok after a few PM's :whistling:Ive taken on some suggestions to the design like the addition of oil seals in front of the taper bearings and an oil gallery possibly for pumped cooling, and the addition of R8 collet dimentions, so any more input would be very usefull IE bearing type, coolant type, tool holder size and the such...:question:
Attachment 4311
hola que tal amigo estaba buscado en la red y di con tu proyecto no se si podras ayudarme lo que pasa estoy haciendo un proyectito para poder mandar el dro del mach3 a un lcd por medio del modbus a un pic y un lcd justo como tu lo hiciste no se si podras ayudarme y facilitarme tu proyecto te agradesco de antemano disculpa mi ingles mascado
hello, this friend was searched on the net and came across your project if you can not help what I'm doing a small project of going to the mach3 to send the drug to a lcd via modbus a pic and lcd just like you so did not know if you can help me and give me your project in advance agradesco you excuse my English chewed
Moderator Note: Not sure how this relates, but if any of you speak Spanish and can do a better translation than Google...
Thanks to the Mod for the translation.
Hi Dzero, From what i can read you would like to know how to send DRO information from mach3 to an LCD using a pic microcontroler, well i never got round to doing this, i got a pokeys55 and just followed the instructions as i needed some more inputs and 55 was plenty. I will post a request and see if anybody has done it with a pic...
Rick
I have posted the question to the forum please follow this link and keep an eye on it for information..
http://www.mycncuk.com/forums/showth...-Mach3-and-LCD
Ok sorry to wake this thread again, but it is relevant. The lenze 534 spindle control unit went up in a puff of smoke, even after surgery by a good spirited member, it finally drew its last amp whilst re-connecting. After shedding a solo tear the knowlegable i2i pointed me in the direction of Sprint Electric Sprint Electric - DC Motor Control Technology after a few emails to the Helpfull engineers there, I arrived at the 1220 1Q 12.2A 1.8kW, 2Hp @180V Unit. It sat in the workshop for 2 months. Today i got the Lenze 534 manual and the Sprint 1220 manual and swapped the wires over and after a little tweeking like magic the old girl wizzed out 4500 rpm no probs. So there you have it.. Lenze 534 dead?? get over to those nice chaps at Sprint..
Rick
I love happy endings.
any more update here do you still have the machine
did you ever get the dro to read out on the lcd screen
does the spindle speed indicator work great pm sent as well
